SPECIFICATION |
| Dimension |
Optional |
| Chassis |
Heavy duty and extra durability designed I beam opting for high tensile steel Q345, welded by automatic submerged-Arc processes .Top flange 14mm, width 140mm;Middle Flange 8mmm;bottom flange 16mm, width 140mm |
| Axel |
Number |
Optional |
Brand |
Optional Upon Choice |
Capacity 13T |
| Suspension |
Mechanical suspension or Air suspension |
| Leaf spring |
Leaf spring or air bag |
| Tank body |
Mm thickness aluminum 5454 |
| Tire |
11.00R20.12.00R2011R22.5.12R22.5.315/80R22.5 Tire Optional |
| Wheel rim |
8.5-20,9.0-20,8.25-22,5.9.0-22.5 steel wheel rim optional upon choice |
| Traction pin |
2”/3.5” bolt-in king pin |
| Landing gear |
JOST brand two-speed, manual operation, heavy duty landing gear |
| Twist Lock |
/ |
| Vehicular application |
/ |
| Braking System |
WABCO RE6 relay valve; T30/30 spring break chamber;40L air tanks. |
| Painting |
Complete chassis sand blasting to clean rust, 1 coat of anticorrosive prime.2coats of final paint. |
| Accessories |
1 standard toolbox |
| Spare tire carrier |
2 Spare tire carrier without spare tires |
