| Medium |
|
Petrol/Disel |
| Model |
|
CLY9460GYYA |
| Dimension(L*W*H) |
|
12800*2500*3550mm |
| Kerb mass |
|
6,500kg |
| Loading type |
|
Top & downloading |
| Test pressure |
|
0.02MPa |
| Temp. |
|
0~50℃ |
| Tank shape |
|
Ellipse, gooseneck, none-subframe |
| Capacity |
|
45,000L |
| Compartmens |
6 |
(7,500L/7,500L/7,500L/7,500L/7,500L/7,500L） |
| Tank material |
|
aluminium 5182/6mm |
| End plate |
2 |
aluminium 5182/6.5mm, disc shape |
| Partition plate |
6 |
aluminium 5182/6mm, disc shape |
| Anti-weave plate |
2 |
aluminium 5182/6mm, disc shape |
| Tank body and frame |
|
Welding |
| Manhole |
6 |
20″ aluminium manhole with 10″ loading hole and breathing valve, China brand, one/compartment. |
| Foot valve |
6 |
4″ aluminium foot valve, China brand, one/compartment |
| Discharging pipe |
|
4″ aluminium |
| Discharging valve |
1 |
one 4″ aluminium API valve + six 3″ball valves |
| Pneumatical system |
1 |
China brand |
| Vapor recovery and anti-overflow |
|
China brand |
| Ladder |
1 |
Rear |
| Protection on top |
1 |
Aluminium, manual |
| Walkway on top |
|
Aluminium anti-slide walkway |
| Coaming |
|
Aluminium |
| Discharging hose box |
2 |
Aluminium |
| Discharging hose |
2 |
3″ discharging hose with 3″coupling |
| Operation box |
1 |
Aluminium, left side of the tank. |
| Toolbox |
1 |
Aluminium |
| Mud guard |
|
Integral, steel, high strength |
| Side protection |
|
Aluminium |
| Rear bumper |
|
Aluminum & steel |
| Spare tyre bracket |
2 |
Steel |
| Fire extinguisher bracket |
2 |
Steel |
| Fire extinguisher |
2 |
8Kg dry powder |
| Anti-static device |
|
towing, copper piece, reel |
| Reflextors |
|
3M reflextors |
| Electric system |
|
24V，LED lights,international seven star jack |
| Model |
|
CIMC |
| Frame |
|
Steel |
| King-pin |
|
90#(replcable by 50#)，JOST |
| Landing gear |
|
JOST E100, one sided operation type |
| Axle |
3 |
BPW axle (first alxe liftable) |
| Suspension |
|
BPW air suspension |
| Tyre |
12+1 |
315/65R 22.5 China brand |
| Rim |
12+1 |
Aluminum |
| ABS |
|
WABCO |
| Painting & Color |
|
Two layers painting, White |
| Standard |
|
As factory’s standard |
